| Equipped with |
| · Superior quality & results |
| · Aluminium die cast stand, corrosion free Moveable Condenser |
| Technical Specification |
| · Magnification: 50X & 1000X |
| · Paired Wide Field: 10X |
| · Achromatic Semi Plan Objective: 5X, 10X, 40X(SL), 100X (SL) Oil Immersion |
| · Nose Piece: Quadruple revolves on ball bearing. |
| · Mechanical stage: 125X135mm size is having low positioned co-axial controls on ball bearing. |
| · Head: Binocular head inclined at 45 and rotatable at 360 . Diopter
adjustment ring. |
| · Interpupillary distance: Adjustable from 55-75 mm |
| · Focusing: Coaxial focusing system, pre-focussing lever and tension
adjustment ring. Slow motion travels 0.02mm in 1 division. |
| Illuminator |
| · Built in base illumination system with 6V-20W halogen lamp OR |
| · Built in base illumination system with 3 Watt LED lamp |
